Diffraction project datasets exp120_8fpm
- Resolution: 1.6 Å
- Space group: P 43 21 2
Uniprot website for P00698
PDB website for 8FPM
PDB validation report for 8FPM
doi:10.18430/M38FPM
Project details
| Title | Crystal structure of hen egg white lysozyme |
| Authors | Lima, L.M.T.R., Ramos, N.G. |
| R / Rfree | 0.24 / 0.28 |
| Unit cell edges [Å] | 77.74 x 77.74 x 37.10 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset exp_120_1_##.img details
| Number of frames | 26 (1 - 26) |
| Distance [mm] | 61.0 |
| Omega [°] | -77.0 |
| Kappa / Chi [°] | -68.0 |
| Phi [°] | -94.0 |
| Wavelength [Å] | 1.54184 |
| Experiment Date | 2020-08-28 |
| Equipment | HOME_SOURCE at HOME_SOURCE (Home Source) |
Dataset exp_120_2_##.img details
| Number of frames | 42 (1 - 42) |
| Distance [mm] | 61.0 |
| Omega [°] | -39.0 |
| Kappa / Chi [°] | -68.0 |
| Phi [°] | -94.0 |
| Wavelength [Å] | 1.54184 |
| Experiment Date | 2020-08-28 |
| Equipment | HOME_SOURCE at HOME_SOURCE (Home Source) |
Dataset exp_120_3_##.img details
| Number of frames | 45 (1 - 45) |
| Distance [mm] | 61.0 |
| Omega [°] | 55.0 |
| Kappa / Chi [°] | -178.0 |
| Phi [°] | -180.0 |
| Wavelength [Å] | 1.54184 |
| Experiment Date | 2020-08-28 |
| Equipment | HOME_SOURCE at HOME_SOURCE (Home Source) |
