Diffraction project datasets IDP91646_4zqn
- Resolution: 2.0 Å
- Space group: I 4
PDB website for 4ZQN
PDB validation report for 4ZQN
doi:10.18430/m34zqn
Project details
| Title | Crystal Structure of the Catalytic Domain of the Inosine Monophosphate Dehydrogenase from Mycobacterium tuberculosis in the complex with IMP and the inhibitor P41 |
| Authors | Kim, Y., Makowska-Grzyska, M., Gu, M., Kavitha, M., Hedstrom, L., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.18 / 0.22 |
| Unit cell edges [Å] | 87.94 x 87.94 x 84.76 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset p41-m3f2suc2.####.img details
| Number of frames | 120 (1 - 120) |
| Distance [mm] | 300.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -110.0 |
| Wavelength [Å] | 0.97899 |
| Experiment Date | 2013-04-14 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
