Diffraction project datasets IDP91046_4ecl
- Method: SAD
- Resolution: 2.017 Å
- Space group: P 1 21 1
PDB website for 4ECL
PDB validation report for 4ECL
doi:10.18430/m34ecl
Project details
| Title | Crystal structure of the cytoplasmic domain of vancomycin resistance serine racemase VanTg |
| Authors | Stogios, P.J., Wawrzak, Z., Minasov, G., Evdokimova, E., Egorova, O., Cosme, J., Di Leo, R., Krishnamoorthy, M., Meziane-Cherif, D., Courvalin, P., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.18 / 0.23 |
| Unit cell edges [Å] | 78.68 x 82.34 x 117.47 |
| Unit cell angles [°] | 90.0, 90.1, 90.0 |
Dataset IDP91046-2.### details
| Number of frames | 477 (1 - 477) |
| Distance [mm] | 280.0 |
| Oscillation width [°] | 0.75 |
| Wavelength [Å] | 0.97856 |
| Experiment Date | 2010-07-31 |
| Equipment | 21-ID-G at APS (Advanced Photon Source) |
Dataset IDP91046-2b.### details
| Number of frames | 21 (460 - 480) |
| Distance [mm] | 280.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 344.25 |
| Wavelength [Å] | 0.97856 |
| Experiment Date | 2010-07-31 |
| Equipment | 21-ID-G at APS (Advanced Photon Source) |
