Diffraction project datasets IDP90905_3p4e
- Method: Molecular Replacement
- Resolution: 1.77 Å
- Space group: P 32 2 1
PDB website for 3P4E
PDB validation report for 3P4E
doi:10.18430/m33p4e
Project details
| Title | Phosphoribosylformylglycinamidine cyclo-ligase from Vibrio cholerae |
| Authors | Osipiuk, J., Zhou, M., Papazisi, L., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.15 / 0.18 |
| Unit cell edges [Å] | 106.28 x 106.28 x 61.38 |
| Unit cell angles [°] | 90.0, 90.0, 120.0 |
Dataset idp90905_3P4E.####.img details
| Number of frames | 230 (1 - 230) |
| Distance [mm] | 256.5 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | 0.0002 |
| Phi [°] | -0.0108 |
| Wavelength [Å] | 0.97924 |
| Experiment Date | 2010-08-22 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
