Diffraction project datasets IDP90832_3r9u
- Method: SAD
- Resolution: 2.36 Å
- Space group: C 2 2 2
PDB website for 3R9U
PDB validation report for 3R9U
doi:10.18430/m33r9u
Project details
| Title | Thioredoxin-disulfide reductase from Campylobacter jejuni. |
| Authors | Osipiuk, J., Zhou, M., Kwon, K., Anderson, K.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.25 |
| Unit cell edges [Å] | 154.01 x 163.57 x 66.88 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset idp90832_3R9U.####.img details
| Number of frames | 180 (1 - 180) |
| Distance [mm] | 327.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -90.0 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0037 |
| Wavelength [Å] | 0.97942 |
| Experiment Date | 2010-10-13 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
