Diffraction project datasets IDP90828_3tpf
- Method: Molecular Replacement
- Resolution: 2.7 Å
- Space group: P 21 21 2
PDB website for 3TPF
PDB validation report for 3TPF
doi:10.18430/m3gp4p
Project details
| Title | Crystal structure of anabolic ornithine carbamoyltransferase from Campylobacter jejuni subsp. jejuni NCTC 11168 |
| Authors | Shabalin, I.G., Onopriyenko, O., Grimshaw, S., Porebski, P.J., Grabowski, M., Savchenko, A., Chruszcz, M., Anderson, W.F., Minor, W., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.20 / 0.24 |
| Unit cell edges [Å] | 157.16 x 87.40 x 141.56 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset IDP90828_crystal2_1_####.img details
| Number of frames | 200 (1 - 200) |
| Distance [mm] | 300.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -95.0 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0108 |
| Wavelength [Å] | 0.97929 |
| Experiment Date | 2010-03-19 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset IDP90828_crystal2_2_####.img details
| Number of frames | 200 (1 - 200) |
| Distance [mm] | 300.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -95.0 |
| Kappa / Chi [°] | 0.0002 |
| Phi [°] | 44.9834 |
| Wavelength [Å] | 0.97929 |
| Experiment Date | 2010-03-19 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
