Diffraction project datasets IDP90722_3ouz
- Method: SAD
- Resolution: 1.902 Å
- Space group: P 21 21 21
PDB website for 3OUZ
PDB validation report for 3OUZ
doi:10.18430/m33ouz
Project details
| Title | Crystal Structure of Biotin Carboxylase-ADP complex from Campylobacter jejuni |
| Authors | Maltseva, N., Kim, Y., Makowska-Grzyska, M., Mulligan, R., Papazisi, L., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.15 / 0.18 |
| Unit cell edges [Å] | 89.86 x 100.67 x 147.70 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset ATPM1E10gly-peak.####.img details
| Number of frames | 135 (1 - 135) |
| Distance [mm] | 260.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -100.0 |
| Kappa / Chi [°] | 0.0002 |
| Phi [°] | -0.0108 |
| Wavelength [Å] | 0.97924 |
| Experiment Date | 2010-08-22 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
