Diffraction project datasets IDP90722_3ouu

  • Method: Molecular Replacement
  • Resolution: 2.25 Å
  • Space group: P 21 21 21
Download all images (962.9 MB)

PDB website for 3OUU

doi:10.18430/M33OUU

Project details

Title Crystal Structure of Biotin Carboxylase-beta-gamma-ATP Complex from Campylobacter jejuni
Authors Maltseva, N., Kim, Y., Makowska-Grzyska, M., Mulligan, R., Papazisi, L., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
R / Rfree 0.17 / 0.22
Unit cell edges [Å] 89.83 x 100.17 x 148.70
Unit cell angles [°] 90.0, 90.0, 90.0

Dataset m1g12-peak.####.img details

Number of frames 152 (1 - 152)
Distance [mm] 320.0
Oscillation width [°] 1.00
Omega [°] -110.0
Kappa / Chi [°] 0.0002
Phi [°] -0.0108
Wavelength [Å] 0.97924
Experiment Date 2010-08-24
Equipment 19-ID at APS (Advanced Photon Source)
