Diffraction project datasets IDP90611_3lv8

  • Method: Molecular Replacement
  • Resolution: 1.8 Å
  • Space group: P 43 3 2
Download all images (327.0 MB)

PDB website for 3LV8

doi:10.18430/M33LV8

Project details

Title 1.8 Angstrom resolution crystal structure of a thymidylate kinase (tmk) from Vibrio cholerae O1 biovar eltor str. N16961 in complex with TMP, thymidine-5'-diphosphate and ADP
Authors Halavaty, A.S., Minasov, G., Dubrovska, I., Winsor, J., Shuvalova, L., Kwon, K., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)
R / Rfree 0.16 / 0.20
Unit cell edges [Å] 112.97 x 112.97 x 112.97
Unit cell angles [°] 90.0, 90.0, 90.0

Dataset idp90611b.### details

Number of frames 75 (1 - 75)
Distance [mm] 200.0
Oscillation width [°] 0.60
Phi [°] 192.0
Wavelength [Å] 0.97872
Experiment Date 2010-02-10
Equipment 21-ID-F at APS (Advanced Photon Source)
