Diffraction project datasets IDP90564_3m6l
- Method: Molecular Replacement
- Resolution: 1.59 Å
- Space group: C 1 2 1
PDB website for 3M6L
PDB validation report for 3M6L
doi:10.18430/m33m6l
Project details
| Title | Crystal structure of transketolase in complex with thiamine diphosphate, ribose-5-phosphate and calcium ion |
| Authors | Nocek, B., Makowska-Grzyska, M., Maltseva, N., Joachimiak, A., Anderson, W., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.16 / 0.20 |
| Unit cell edges [Å] | 130.92 x 71.46 x 69.62 |
| Unit cell angles [°] | 90.0, 109.5, 90.0 |
Dataset tk-xf12-soak-ca-2.####.img details
| Number of frames | 200 (1 - 200) |
| Distance [mm] | 229.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | -0.0001 |
| Phi [°] | -0.007 |
| Wavelength [Å] | 0.97933 |
| Experiment Date | 2010-02-11 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
