Diffraction project datasets IDP52183_6edv
- Resolution: 1.35 Å
- Space group: P 21 21 21
PDB website for 6EDV
PDB validation report for 6EDV
doi:10.18430/m36edv
Project details
| Title | Structure of a GNAT superfamily acetyltransferase PA3944 in complex with CoA |
| Authors | Majorek, K.A., Satchell, K.J.F., Joachimiak, A., Minor, W., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.13 / 0.16 |
| Unit cell edges [Å] | 36.44 x 44.03 x 111.64 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset APC6869_KaM_1_4_1_####.img details
| Number of frames | 700 (1 - 700) |
| Distance [mm] | 180.0 |
| Oscillation width [°] | 0.30 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2012-03-04 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset APC6869_KaM_1_4_2_####.img details
| Number of frames | 220 (1 - 220) |
| Distance [mm] | 180.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2012-03-04 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
