Diffraction project datasets IDP05583_4hde
- Resolution: 1.317 Å
- Space group: P 21 21 21
PDB website for 4HDE
PDB validation report for 4HDE
doi:10.18430/m34hde
Project details
| Title | The crystal structure of a SCO1/SenC family lipoprotein from Bacillus anthracis str. Ames |
| Authors | Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.16 / 0.19 |
| Unit cell edges [Å] | 34.99 x 48.47 x 88.55 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset IDP05583_PKa.####.img details
| Number of frames | 120 (1 - 120) |
| Distance [mm] | 141.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -30.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97937 |
| Experiment Date | 2012-07-23 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
