Diffraction project datasets IDP05166_5ewq
- Resolution: 2.57 Å
- Space group: P 1
PDB website for 5EWQ
PDB validation report for 5EWQ
doi:10.18430/m35ewq
Project details
| Title | The crystal structure of an amidase family protein from Bacillus anthracis str. Ames |
| Authors | Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.22 / 0.25 |
| Unit cell edges [Å] | 77.39 x 89.56 x 89.60 |
| Unit cell angles [°] | 112.0, 106.6, 106.6 |
Dataset IDP05133_INa.####.img details
| Number of frames | 210 (1 - 210) |
| Distance [mm] | 327.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -90.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97951 |
| Experiment Date | 2012-07-23 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset IDP05133_PKa.####.img details
| Number of frames | 180 (1 - 180) |
| Distance [mm] | 327.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -90.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97937 |
| Experiment Date | 2012-07-23 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
