Diffraction project datasets IDP05166_4s1n
- Resolution: 2.7 Å
- Space group: P 21 21 21
PDB website for 4S1N
PDB validation report for 4S1N
doi:10.18430/m34s1n
Project details
| Title | The crystal structure of phosphoribosylglycinamide formyltransferase from Streptococcus pneumoniae TIGR4 |
| Authors | Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.20 / 0.28 |
| Unit cell edges [Å] | 43.21 x 46.23 x 91.15 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset IDP05133_INa.####.img details
| Number of frames | 210 (1 - 210) |
| Distance [mm] | 327.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -90.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97951 |
| Experiment Date | 2012-07-23 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset IDP05133_PKa.####.img details
| Number of frames | 180 (1 - 180) |
| Distance [mm] | 327.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -90.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97937 |
| Experiment Date | 2012-07-23 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
