Diffraction project datasets IDP04645_4mam
- Resolution: 1.474 Å
- Space group: P 21 21 21
PDB website for 4MAM
PDB validation report for 4MAM
doi:10.18430/m34mam
Project details
| Title | The crystal structure of phosphoribosylaminoimidazole carboxylase ATPase subunit of Francisella tularensis subsp. tularensis SCHU S4 in complex with an ADP analog, AMP-CP |
| Authors | Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.16 / 0.18 |
| Unit cell edges [Å] | 73.24 x 85.39 x 127.12 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset IDP04645Bcomp.####.img details
| Number of frames | 85 (1 - 85) |
| Distance [mm] | 201.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -120.0 |
| Wavelength [Å] | 0.97860 |
| Experiment Date | 2013-08-02 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset IDP04645Bcomp_Cont.####.img details
| Number of frames | 60 (81 - 140) |
| Distance [mm] | 201.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -40.0 |
| Wavelength [Å] | 0.97860 |
| Experiment Date | 2013-08-02 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
