Diffraction project datasets IDP04633_5hw2
- Resolution: 2.054 Å
- Space group: P 43
PDB website for 5HW2
PDB validation report for 5HW2
doi:10.18430/m35hw2
Project details
| Title | Crystal Structure of Adenylosuccinate Lyase from Francisella tularensis Complexed with fumaric acid |
| Authors | Chang, C., Maltseva, N., Kim, Y., Shatsman, S., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.25 |
| Unit cell edges [Å] | 88.68 x 88.68 x 255.67 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset inB6eg.####.img details
| Number of frames | 200 (1 - 200) |
| Distance [mm] | 280.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -120.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97921 |
| Experiment Date | 2012-03-21 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
