Diffraction project datasets IDP04560_3nua
- Method: Molecular Replacement
- Resolution: 1.4 Å
- Space group: P 21 21 2
PDB website for 3NUA
PDB validation report for 3NUA
doi:10.18430/m33nua
Project details
| Title | Crystal Structure of Phosphoribosylaminoimidazole-Succinocarboxamide Synthase from Clostridium perfringens |
| Authors | Kim, Y., Mulligan, R., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.14 / 0.16 |
| Unit cell edges [Å] | 80.88 x 148.91 x 45.32 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset a2c1-peak.####.img details
| Number of frames | 220 (1 - 220) |
| Distance [mm] | 180.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | 0.0002 |
| Phi [°] | -0.0108 |
| Wavelength [Å] | 0.97929 |
| Experiment Date | 2010-03-28 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
