Diffraction project datasets IDP04500_4np6
- Resolution: 2.004 Å
- Space group: P 43
PDB website for 4NP6
PDB validation report for 4NP6
doi:10.18430/m34np6
Project details
| Title | Crystal Structure of Adenylate Kinase from Vibrio cholerae O1 biovar eltor |
| Authors | Kim, Y., Zhou, M., Grimshaw, S., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.22 |
| Unit cell edges [Å] | 101.62 x 101.62 x 89.64 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset I20su.####.img details
| Number of frames | 120 (1 - 120) |
| Distance [mm] | 280.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97910 |
| Experiment Date | 2012-03-09 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
