Diffraction project datasets IDP04293_3oxp
- Method: SAD
- Resolution: 1.2 Å
- Space group: P 21 21 21
PDB website for 3OXP
PDB validation report for 3OXP
doi:10.18430/m33oxp
Project details
| Title | Structure of phosphotransferase enzyme II, A component from Yersinia pestis CO92 at 1.2 A resolution |
| Authors | Filippova, E.V., Wawrzak, Z., Kudritska, M., Edwards, A., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.15 / 0.18 |
| Unit cell edges [Å] | 56.91 x 57.95 x 78.74 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset anomalous_IDP04293-1.### details
| Number of frames | 360 (1 - 360) |
| Distance [mm] | 200.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 60.0 |
| Wavelength [Å] | 0.97856 |
| Experiment Date | 2010-07-31 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
Dataset non-anomalous_IDP04293-1.### details
| Number of frames | 300 (1 - 300) |
| Distance [mm] | 140.0 |
| Oscillation width [°] | 0.50 |
| Wavelength [Å] | 0.96107 |
| Experiment Date | 2010-08-13 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
