Diffraction project datasets IDP04160_3nav
- Method: Molecular Replacement
- Resolution: 2.1 Å
- Space group: P 21 21 21
PDB website for 3NAV
PDB validation report for 3NAV
doi:10.18430/m33nav
Project details
| Title | Crystal structure of an alpha subunit of tryptophan synthase from Vibrio cholerae O1 biovar El Tor str. N16961 |
| Authors | Nocek, B., Makowska-Grzyska, M., Kwon, K., Anderson, A., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.18 / 0.23 |
| Unit cell edges [Å] | 57.59 x 60.38 x 141.20 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset xtal-1-anl-1-G8.####.img details
| Number of frames | 180 (1 - 180) |
| Distance [mm] | 309.7 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -105.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0108 |
| Wavelength [Å] | 0.97929 |
| Experiment Date | 2010-04-24 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
