Diffraction project datasets IDP02771_3qtt
- Method: SAD
- Resolution: 2.599 Å
- Space group: P 43
PDB website for 3QTT
PDB validation report for 3QTT
doi:10.18430/m33qtt
Project details
| Title | Crystal Structure of Pantoate-beta-alanine Ligase from Francisella tularensis Complexed with Beta-gamma ATP and Beta-alanine |
| Authors | Maltseva, N., Kim, Y., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.17 / 0.25 |
| Unit cell edges [Å] | 47.15 x 47.15 x 257.66 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset if1eg-peak.####.img details
| Number of frames | 181 (1 - 181) |
| Distance [mm] | 350.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -120.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0037 |
| Wavelength [Å] | 0.97912 |
| Experiment Date | 2010-12-09 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
