Diffraction project datasets IDP02454_3hyl
- Method: SAD
- Resolution: 2.16 Å
- Space group: C 1 2 1
PDB website for 3HYL
PDB validation report for 3HYL
doi:10.18430/m33hyl
Project details
| Title | Crystal Structure of Transketolase from Bacillus anthracis |
| Authors | Maltseva, N., Kim, Y., Kwon, K., Joachimiak, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.18 / 0.23 |
| Unit cell edges [Å] | 138.80 x 70.98 x 145.80 |
| Unit cell angles [°] | 90.0, 117.4, 90.0 |
Dataset ANL1A5gly1-peak.####.img details
| Number of frames | 220 (1 - 220) |
| Distance [mm] | 220.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0009 |
| Wavelength [Å] | 0.97918 |
| Experiment Date | 2009-06-04 |
| Equipment | 19-BM at APS (Advanced Photon Source) |
