Diffraction project datasets IDP02280_3l44
- Method: SAD
- Resolution: 2.05 Å
- Space group: P 21 21 21
PDB website for 3L44
doi:10.18430/M33L44
Project details
| Title | Crystal structure of Bacillus anthracis HemL-1, glutamate semialdehyde aminotransferase |
| Authors | Anderson, S.M., Wawrzak, Z., Gordon, E., Hasseman, J., Edwards, A., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.16 / 0.19 |
| Unit cell edges [Å] | 75.84 x 93.92 x 105.64 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset idp02280-1_A.### details
| Number of frames | 240 (1 - 240) |
| Distance [mm] | 185.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 80.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2009-11-13 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
Dataset idp02280-1_B.### details
| Number of frames | 240 (1 - 240) |
| Distance [mm] | 185.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 260.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2009-11-13 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
