Diffraction project datasets IDP02260_5far
- Resolution: 2.0 Å
- Space group: P 1 21 1
PDB website for 5FAR
PDB validation report for 5FAR
doi:10.18430/m35far
Project details
| Title | Crystal structure of dihydroneopterin aldolase from Bacillus anthracis complex with 9-METHYLGUANINE |
| Authors | Chang, C., Maltseva, N., Kim, Y., Shatsman, S., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.23 |
| Unit cell edges [Å] | 63.80 x 138.21 x 63.93 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset 9metguM1F2eg.####.img details
| Number of frames | 270 (1 - 270) |
| Distance [mm] | 280.2 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -150.0 |
| Wavelength [Å] | 0.97934 |
| Experiment Date | 2015-07-19 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
