Diffraction project datasets IDP02154_4mph

  • Method: SAD
  • Resolution: 2.03 Å
  • Space group: I 2 2 2
Download all images (2.4 GB)

PDB website for 4MPH

doi:10.18430/M34MPH

Project details

Title Crystal structure of BaLdcB / VanY-like L,D-carboxypeptidase Zinc(II)-bound
Authors Hoyland, C.N., Aldridge, C., Cleverley, R.M., Duchene, M.C., Minasov, G., Onopriyenko, O., Sidiq, K., Stogios, P.J., Anderson, W.F., Daniel, R.A., Savchenko, A., Vollmer, W., Lewis, R.J.
R / Rfree 0.15 / 0.19
Unit cell edges [Å] 76.83 x 112.34 x 125.67
Unit cell angles [°] 90.0, 90.0, 90.0

Dataset GBAA2526-1.### details

Number of frames 200 (1 - 200)
Distance [mm] 200.0
Oscillation width [°] 0.75
Phi [°] 115.0
Wavelength [Å] 1.28223
Experiment Date 2013-08-18
Equipment 21-ID-D at APS (Advanced Photon Source)

Dataset GBAA2526-1b.### details

Number of frames 150 (1 - 150)
Distance [mm] 200.0
Oscillation width [°] 1.00
Phi [°] 115.0
Wavelength [Å] 1.28223
Experiment Date 2013-08-18
Equipment 21-ID-D at APS (Advanced Photon Source)
