Diffraction project datasets IDP01861_3igs
- Method: SAD
- Resolution: 1.5 Å
- Space group: C 1 2 1
PDB website for 3IGS
PDB validation report for 3IGS
doi:10.18430/m33igs
Project details
| Title | Structure of the Salmonella enterica N-acetylmannosamine-6-phosphate 2-epimerase |
| Authors | Anderson, S.M., Wawrzak, Z., Gordon, E., Skarina, T., Papazisi, L., Anderson, W.F., Savchenko, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.15 / 0.18 |
| Unit cell edges [Å] | 183.29 x 63.32 x 41.80 |
| Unit cell angles [°] | 90.0, 91.3, 90.0 |
Dataset IDP01861-3_A.### details
| Number of frames | 260 (1 - 260) |
| Distance [mm] | 160.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 105.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2009-06-11 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
Dataset IDP01861-3_B.### details
| Number of frames | 260 (1 - 260) |
| Distance [mm] | 160.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 285.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2009-06-11 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
