Diffraction project datasets IDP01826_3lay
- Method: Molecular Replacement
- Resolution: 2.7 Å
- Space group: P 21 21 2
PDB website for 3LAY
PDB validation report for 3LAY
doi:10.18430/m33lay
Project details
| Title | Alpha-Helical barrel formed by the decamer of the zinc resistance-associated protein (STM4172) from Salmonella enterica subsp. enterica serovar Typhimurium str. LT2 |
| Authors | Filippova, E.V., Minasov, G., Shuvalova, L., Winsor, J., Dubrovska, I., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.22 / 0.27 |
| Unit cell edges [Å] | 100.80 x 148.91 x 74.54 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset idp01826k.### details
| Number of frames | 300 (1 - 300) |
| Distance [mm] | 400.0 |
| Oscillation width [°] | 0.60 |
| Phi [°] | 100.0 |
| Wavelength [Å] | 0.97856 |
| Experiment Date | 2009-11-25 |
| Equipment | 21-ID-G at APS (Advanced Photon Source) |
