Diffraction project datasets IDP01750_3rzq
- Resolution: 1.62 Å
- Space group: C 1 2 1
PDB website for 3RZQ
PDB validation report for 3RZQ
doi:10.18430/m33rzq
Project details
| Title | Crystal Structure of the H233A mutant of 7-cyano-7-deazaguanine reductase, QueF from Vibrio cholerae complexed with preQ0 |
| Authors | Y.Kim,M.Zhou,M.Gu,W.F.Anderson,A.Joachimiak,Center For Structural Genomics Of Infectious Diseases (Csgid) |
| R / Rfree | 0.15 / 0.18 |
| Unit cell edges [Å] | 123.11 x 72.26 x 81.76 |
| Unit cell angles [°] | 90.0, 131.3, 90.0 |
Dataset 233a-q0-m1b4-peak.####.img details
| Number of frames | 220 (1 - 220) |
| Distance [mm] | 240.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -120.0 |
| Phi [°] | -0.0037 |
| Wavelength [Å] | 0.97929 |
| Experiment Date | 2010-12-10 |
