Diffraction project datasets IDP01723_3kax
- Resolution: 1.7 Å
- Space group: P 21 21 21
PDB website for 3KAX
doi:10.18430/M33KAX
Project details
| Title | Crystal structure of a putative C-S lyase from Bacillus anthracis |
| Authors | Anderson, S.M., Wawrzak, Z., Gordon, E., Peterson, S., Savchenko, A., Anderson, W.F. |
| R / Rfree | 0.18 / 0.22 |
| Unit cell edges [Å] | 53.47 x 85.18 x 172.18 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset idp1723-1_A.### details
| Number of frames | 260 (1 - 260) |
| Distance [mm] | 170.0 |
| Oscillation width [°] | 0.50 |
| Phi [°] | 160.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2009-07-12 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
Dataset idp1723-1_B.### details
| Number of frames | 260 (1 - 260) |
| Distance [mm] | 170.0 |
| Oscillation width [°] | 0.50 |
| Phi [°] | 340.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2009-07-12 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
