Diffraction project datasets IDP01616_4ncz
- Method: Molecular Replacement
- Resolution: 1.89 Å
- Space group: I 2 2 2
PDB website for 4NCZ
PDB validation report for 4NCZ
doi:10.18430/m34ncz
Project details
| Title | Spermidine N-acetyltransferase from Vibrio cholerae in complex with 2-[n-cyclohexylamino]ethane sulfonate. |
| Authors | Osipiuk, J., Zhou, M., Gu, M., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.24 |
| Unit cell edges [Å] | 71.75 x 134.50 x 137.09 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset 2Ux_24.#### details
| Number of frames | 56 (1 - 56) |
| Distance [mm] | 200.5 |
| Oscillation width [°] | 0.50 |
| Omega [°] | -99.45 |
| Phi [°] | 45.0 |
| Wavelength [Å] | 0.97923 |
| Experiment Date | 2008-10-16 |
| Equipment | 19-BM at APS (Advanced Photon Source) |
Dataset 2Ux_24.#### details
| Number of frames | 360 (101 - 460) |
| Distance [mm] | 185.2 |
| Oscillation width [°] | 0.50 |
| Omega [°] | -99.45 |
| Phi [°] | 45.0 |
| Wavelength [Å] | 0.97923 |
| Experiment Date | 2008-10-16 |
| Equipment | 19-BM at APS (Advanced Photon Source) |
