Diffraction project datasets IDP01207_3r5x
- Method: SAD
- Resolution: 2.0 Å
- Space group: P 1
PDB website for 3R5X
doi:10.18430/M33R5X
Project details
| Title | Crystal Structure of D-alanine--D-Alanine Ligase from Bacillus anthracis complexed with ATP |
| Authors | Kim, Y., Hasseman, J., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.18 / 0.22 |
| Unit cell edges [Å] | 56.34 x 68.99 x 92.39 |
| Unit cell angles [°] | 73.4, 85.0, 75.5 |
Dataset a2f11e-peak.####.img details
| Number of frames | 200 (1 - 200) |
| Distance [mm] | 270.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -100.0 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0108 |
| Wavelength [Å] | 0.97934 |
| Experiment Date | 2010-06-04 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
