Diffraction project datasets IDP01195_3sc6

  • Method: Molecular Replacement
  • Resolution: 2.65 Å
  • Space group: P 1 21 1
Download all images (2.3 GB)

PDB website for 3SC6

doi:10.18430/M33SC6

Project details

Title 2.65 Angstrom resolution crystal structure of dTDP-4-dehydrorhamnose reductase (rfbD) from Bacillus anthracis str. Ames in complex with NADP
Authors Law, A., Stergioulis, A., Halavaty, A.S., Minasov, G., Anderson, W.F., Kuhn, M.L.
R / Rfree 0.22 / 0.26
Unit cell edges [Å] 79.45 x 113.34 x 144.95
Unit cell angles [°] 90.0, 91.2, 90.0

Dataset idp01195b.### details

Number of frames 300 (1 - 300)
Distance [mm] 320.0
Oscillation width [°] 0.60
Phi [°] 176.0
Wavelength [Å] 0.97856
Experiment Date 2011-03-03
Equipment 21-ID-D at APS (Advanced Photon Source)
