Diffraction project datasets IDP01178_4my1
- Resolution: 2.5997 Å
- Space group: P 1
PDB website for 4MY1
PDB validation report for 4MY1
doi:10.18430/m34my1
Project details
| Title | Crystal Structure of the Inosine 5'-monophosphate Dehydrogenase, with a Internal Deletion of CBS Domain from Bacillus anthracis str. Ames complexed with P68 |
| Authors | Kim, Y., Makowska-Grzyska, M., Gu, M., Gorla, S.K., Hedstrom, L., Anderson, W.F., Joachimiak, A., CSGID, Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.25 |
| Unit cell edges [Å] | 83.22 x 89.39 x 103.99 |
| Unit cell angles [°] | 81.1, 90.0, 83.6 |
Dataset p68-indH5eg.####.img details
| Number of frames | 200 (1 - 200) |
| Distance [mm] | 359.9 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -130.0 |
| Kappa / Chi [°] | -0.0003 |
| Phi [°] | -0.0176 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2012-06-18 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
