Diffraction project datasets IDP01115_3ig4

  • Method: SAD
  • Resolution: 2.89 Å
  • Space group: P 43 21 2
Download all images (3.3 GB)

PDB website for 3IG4

doi:10.18430/M33IG4

Project details

Title Structure of a putative aminopeptidase P from Bacillus anthracis
Authors Anderson, S.M., Wawrzak, Z., Skarina, T., Onopriyenko, O., Kwon, K., Anderson, W.F., Savchenko, A., Center for Structural Genomics of Infectious Diseases (CSGID)
R / Rfree 0.20 / 0.23
Unit cell edges [Å] 180.88 x 180.88 x 254.78
Unit cell angles [°] 90.0, 90.0, 90.0

Dataset IDP01115-1.### details

Number of frames 300 (1 - 300)
Distance [mm] 280.0
Oscillation width [°] 0.50
Wavelength [nm] 0.97872
Experiment Date 2009-06-08
Equipment 21-ID-G at APS (Advanced Photon Source)

Dataset IDP01115-1_2_A.### details

Number of frames 200 (1 - 200)
Distance [mm] 280.0
Oscillation width [°] 0.50
Phi [°] 60.0
Wavelength [nm] 0.97872
Experiment Date 2009-06-08
Equipment 21-ID-G at APS (Advanced Photon Source)

Dataset IDP01115-1_2_B.### details

Number of frames 200 (1 - 200)
Distance [mm] 280.0
Oscillation width [°] 0.50
Phi [°] 240.0
Wavelength [nm] 0.97872
Experiment Date 2009-06-08
Equipment 21-ID-G at APS (Advanced Photon Source)
