Diffraction project datasets IDP01100_3k1s
- Method: SAD
- Resolution: 2.3 Å
- Space group: P 43 21 2
PDB website for 3K1S
PDB validation report for 3K1S
doi:10.18430/m33k1s
Project details
| Title | Crystal Structure of the PTS Cellobiose Specific Enzyme IIA from Bacillus anthracis |
| Authors | Anderson, S.M., Wawrzak, Z., Onopriyenko, O., Kwon, K., Anderson, W.F., Savchenko, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.23 |
| Unit cell edges [Å] | 92.89 x 92.89 x 260.64 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset 1100-6_A.### details
| Number of frames | 140 (1 - 140) |
| Distance [mm] | 320.0 |
| Oscillation width [°] | 0.50 |
| Wavelength [Å] | 0.97933 |
| Experiment Date | 2009-04-21 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
Dataset 1100-6_B.### details
| Number of frames | 140 (1 - 140) |
| Distance [mm] | 320.0 |
| Oscillation width [°] | 0.50 |
| Phi [°] | 180.0 |
| Wavelength [Å] | 0.97933 |
| Experiment Date | 2009-04-21 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
