Diffraction project datasets IDP00951_3kbo
- Method: SAD
- Resolution: 2.14 Å
- Space group: C 1 2 1
PDB website for 3KBO
PDB validation report for 3KBO
doi:10.18430/m33kbo
Project details
| Title | 2.14 Angstrom Crystal Structure of Putative Oxidoreductase (ycdW) from Salmonella typhimurium in Complex with NADP |
| Authors | Minasov, G., Wawrzak, Z., Skarina, T., Onopriyenko, O., Papazisi, L., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.21 / 0.27 |
| Unit cell edges [Å] | 279.62 x 45.59 x 112.34 |
| Unit cell angles [°] | 90.0, 101.6, 90.0 |
Dataset idp951-2_A.### details
| Number of frames | 310 (1 - 310) |
| Distance [mm] | 230.0 |
| Oscillation width [°] | 0.50 |
| Phi [°] | 60.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2009-08-13 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
Dataset idp951-2_B.### details
| Number of frames | 310 (1 - 310) |
| Distance [mm] | 230.0 |
| Oscillation width [°] | 0.50 |
| Phi [°] | 240.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2009-08-13 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
