Diffraction project datasets IDP00896_3ga7
- Method: SAD
- Resolution: 1.55 Å
- Space group: C 2 2 21
PDB website for 3GA7
PDB validation report for 3GA7
doi:10.18430/m33ga7
Project details
| Title | 1.55 Angstrom Crystal Structure of an Acetyl Esterase from Salmonella typhimurium |
| Authors | Minasov, G., Wawrzak, Z., Brunzelle, J., Onopriyenko, O., Skarina, T., Peterson, S.N., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.14 / 0.18 |
| Unit cell edges [Å] | 82.75 x 133.21 x 64.14 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset 3ga7_anomalous_stm490-2_2_A.### details
| Number of frames | 240 (1 - 240) |
| Distance [mm] | 180.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 60.0 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2009-02-08 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
Dataset 3ga7_stm490-2.### details
| Number of frames | 200 (1 - 200) |
| Distance [mm] | 200.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 55.0 |
| Wavelength [Å] | 0.99189 |
| Experiment Date | 2009-03-19 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
