Diffraction project datasets IDP00629_3qjg
- Method: Molecular Replacement
- Resolution: 2.04 Å
- Space group: C 1 2 1
PDB website for 3QJG
PDB validation report for 3QJG
doi:10.18430/m33qjg
Project details
| Title | Epidermin biosynthesis protein EpiD from Staphylococcus aureus |
| Authors | Osipiuk, J., Makowska-Grzyska, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.21 / 0.26 |
| Unit cell edges [Å] | 160.99 x 111.26 x 154.57 |
| Unit cell angles [°] | 90.0, 97.3, 90.0 |
Dataset idp00629_3QJG.####.img details
| Number of frames | 130 (3 - 132) |
| Distance [mm] | 218.0 |
| Oscillation width [°] | 0.70 |
| Omega [°] | -88.6 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0009 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2010-08-12 |
| Equipment | 19-BM at APS (Advanced Photon Source) |
Dataset idp00629_3QJG.####.img details
| Number of frames | 40 (301 - 340) |
| Distance [mm] | 194.7 |
| Oscillation width [°] | 0.70 |
| Omega [°] | 2.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0009 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2010-08-12 |
| Equipment | 19-BM at APS (Advanced Photon Source) |
Dataset idp00629_3QJG.####.img details
| Number of frames | 130 (401 - 530) |
| Distance [mm] | 218.0 |
| Oscillation width [°] | 0.70 |
| Omega [°] | 2.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0009 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2010-08-12 |
| Equipment | 19-BM at APS (Advanced Photon Source) |
