Diffraction project datasets IDP00348_3TFC
- Resolution: 1.95 Å
- Space group: C 1 2 1
Uniprot website for Q8Y6T2
PDB website for 3TFC
PDB validation report for 3TFC
doi:10.18430/m33tfc
Project details
| Title | 1.95 Angstrom crystal structure of a bifunctional 3-deoxy-7-phosphoheptulonate synthase/chorismate mutase (aroA) from Listeria monocytogenes EGD-e in complex with phosphoenolpyruvate |
| Authors | Light, S.H., Minasov, G., Halavaty, A.S., Shuvalova, L., Kwon, K., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.17 / 0.20 |
| Unit cell edges [Å] | 110.16 x 110.89 x 80.23 |
| Unit cell angles [°] | 90.0, 127.2, 90.0 |
Dataset idp00348l.### details
| Number of frames | 300 (1 - 300) |
| Distance [mm] | 200.0 |
| Oscillation width [°] | 0.60 |
| Phi [°] | 235.0 |
| Wavelength [Å] | 0.97856 |
| Experiment Date | 2011-07-28 |
| Equipment | 21-ID-G at APS (Advanced Photon Source) |
