Diffraction project datasets IDP00347_3ist
- Method: Molecular Replacement
- Resolution: 1.65 Å
- Space group: P 43 21 2
PDB website for 3IST
PDB validation report for 3IST
doi:10.18430/M33IST
Project details
| Title | Crystal structure of glutamate racemase from Listeria monocytogenes in complex with succinic acid |
| Authors | Majorek, K.A., Chruszcz, M., Skarina, T., Onopriyenko, O., Stam, J., Anderson, W.F., Savchenko, A., Bujnicki, J.M., Minor, W., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.17 / 0.21 |
| Unit cell edges [Å] | 66.42 x 66.42 x 258.77 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset IDP00347_347_lig_1_1_####.img details
| Number of frames | 326 (1 - 326) |
| Distance [mm] | 230.0 |
| Oscillation width [°] | 0.50 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.007 |
| Wavelength [Å] | 0.97934 |
| Experiment Date | 2009-06-14 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
