Diffraction project datasets IDP00340_3tbf
- Method: SAD
- Resolution: 2.28 Å
- Space group: P 1 21 1
PDB website for 3TBF
PDB validation report for 3TBF
doi:10.18430/m33tbf
Project details
| Title | C-terminal domain of glucosamine-fructose-6-phosphate aminotransferase from Francisella tularensis. |
| Authors | Osipiuk, J., Zhou, M., Maltseva, N., Kim, Y., Papazisi, L., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.17 / 0.23 |
| Unit cell edges [Å] | 71.37 x 262.91 x 83.80 |
| Unit cell angles [°] | 90.0, 91.3, 90.0 |
Dataset idp00340_3TBF.####.img details
| Number of frames | 360 (1 - 360) |
| Distance [mm] | 353.1 |
| Oscillation width [°] | 0.50 |
| Omega [°] | -120.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0108 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2011-07-03 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
