Diffraction project datasets IDP00122_3cwc
- Method: SAD
- Resolution: 2.23 Å
- Space group: P 1 21 1
PDB website for 3CWC
PDB validation report for 3CWC
doi:10.18430/m33cwc
Project details
| Title | Crystal structure of putative glycerate kinase 2 from Salmonella typhimurium LT2 |
| Authors | Osipiuk, J., Zhou, M., Holzle, D., Anderson, W., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.24 |
| Unit cell edges [Å] | 63.73 x 59.55 x 103.61 |
| Unit cell angles [°] | 90.0, 106.0, 90.0 |
Dataset IDP00122_3cwc.####.img details
| Number of frames | 180 (1 - 180) |
| Distance [mm] | 327.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -90.0 |
| Kappa / Chi [°] | 0.0002 |
| Phi [°] | -0.0009 |
| Wavelength [Å] | 0.97929 |
| Experiment Date | 2008-03-30 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset IDP00122_3cwc.####.img details
| Number of frames | 180 (301 - 480) |
| Distance [mm] | 327.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -90.0 |
| Kappa / Chi [°] | 0.0002 |
| Phi [°] | 179.9986 |
| Wavelength [Å] | 0.97929 |
| Experiment Date | 2008-03-30 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
