Diffraction project datasets IDP00111_3tv9
- Method: SAD
- Resolution: 2.497 Å
- Space group: P 21 21 2
PDB website for 3TV9
PDB validation report for 3TV9
doi:10.18430/m33tv9
Project details
| Title | Crystal Structure of Putative Peptide Maturation Protein from Shigella flexneri |
| Authors | Kim, Y., Maltseva, N., Gu, M., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.25 |
| Unit cell edges [Å] | 115.13 x 61.12 x 65.10 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset INDA4sucr-peak.####.img details
| Number of frames | 200 (1 - 200) |
| Distance [mm] | 350.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -100.0 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0037 |
| Wavelength [Å] | 0.97937 |
| Experiment Date | 2010-10-31 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
