Diffraction project datasets IDP00079_3e7n
- Method: MAD
- Resolution: 2.45 Å
- Space group: C 1 2 1
PDB website for 3E7N
PDB validation report for 3E7N
doi:10.18430/m33e7n
Project details
| Title | Crystal structure of d-ribose high-affinity transport system from salmonella typhimurium lt2 |
| Authors | Nocek, B., Maltseva, N., Gu, M., Joachimiak, A., Anderson, W., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.23 |
| Unit cell edges [Å] | 293.04 x 92.73 x 93.60 |
| Unit cell angles [°] | 90.0, 106.5, 90.0 |
Dataset peak-1.####.img details
| Number of frames | 180 (1 - 180) |
| Distance [mm] | 327.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0009 |
| Wavelength [Å] | 0.97935 |
| Experiment Date | 2008-06-16 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
