Diffraction project datasets IDP00038_4mjx
- Resolution: 1.4 Å
- Space group: P 43
PDB website for 4MJX
doi:10.18430/M34MJX
Project details
| Title | Crystal structure of the double mutant (S112A, H303A) of B.anthracis mycrocine immunity protein (MccF) |
| Authors | Nocek, B., Anderson, W.F., Severinov, K., Joachimiak, A. |
| R / Rfree | 0.11 / 0.15 |
| Unit cell edges [Å] | 118.38 x 118.38 x 56.25 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset x1-high2.####.img details
| Number of frames | 90 (1 - 90) |
| Distance [mm] | 181.6 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -88.97 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0033 |
| Wavelength [Å] | 0.97931 |
| Experiment Date | 2012-11-02 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset x1-high.####.img details
| Number of frames | 90 (1 - 90) |
| Distance [mm] | 110.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -88.97 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0033 |
| Wavelength [Å] | 0.97931 |
| Experiment Date | 2012-11-02 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset x1.####.img details
| Number of frames | 90 (1 - 90) |
| Distance [mm] | 292.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -88.97 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0033 |
| Wavelength [Å] | 0.97931 |
| Experiment Date | 2012-11-02 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
