Diffraction project datasets IDP01892_3hvu

  • Method: Molecular Replacement
  • Resolution: 1.95 Å
  • Space group: P 1 21 1
Download all images (2.5 GB)

PDB website for 3HVU
PDB validation report for 3HVU

doi:10.18430/m33hvu

Project details

Title 1.95 Angstrom Crystal Structure of Complex of Hypoxanthine-Guanine Phosphoribosyltransferase from Bacillus anthracis with 2-(N-morpholino)ethanesulfonic acid (MES)
Authors Minasov, G., Halavaty, A., Shuvalova, L., Dubrovska, I., Winsor, J., Papazisi, L., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)
R / Rfree 0.19 / 0.23
Unit cell edges [Å] 52.71 x 93.38 x 94.90
Unit cell angles [°] 90.0, 90.0, 90.0

Dataset idp01892a.### details

Number of frames 360 (1 - 360)
Distance [mm] 270.0
Oscillation width [°] 0.50
Phi [°] 90.0
Wavelength [Å] 0.97856
Experiment Date 2009-05-29
Equipment 21-ID-G at APS (Advanced Photon Source)
